Frameset
Frame
INFINITO carbon ICR - 1.5"- 1.5", Disc Brake, Mechanical/Electronic Di2, compatible with 32" tire, BBset pressfit 86,5x41, rear dropout 12 x 142mm thru axle sizes 47-50-53-55-57-59-61cm
Fork
Full Carbon ICR - 28"- 300mm - 1.5" , dropout 12 x 100mm thru axle
Headset
Acros/FSA for ICR cable routing
Drivetrain
Shifters
Ultegra Di2 hydraulic disc brake for road ST-R8170(L), ST-R8170 (R)
Rear Derailleur
Ultegra Di2 12sp RD-R8150, 12-speed, max 34T
Front Derailleur
Ultegra Di2 12sp FD-R8150, Ultegra Di2, brazed-on type
Crankset
Ultegra 12sp FC-R8100, hollowtech 2, for rear 12- speed, 170- 172,5-175mm, 50x34T Crank Length:170mm-47~54cm, 172.5mm-55~59cm, 175mm-61cm
Bottom Bracket
Shimano KSMBB7241B pressfit
Chain
Shimano CN-M8100, 12- speed
Cassette
Ultegra 12sp 11-34T CS-R8100,Ultegra 12sp, 11-12-13-14-15-17-19-21-24- 27-30-34T
Brakes
Brakes
Shimano BR-R8170 Hydraulic disc brake included in the shifter
Rotor
Shimano RT-CL800, 160mm front rear
Wheels
Wheels
Velomann Palladium, 33mm profile, 700x21c, 24h, HG11 body, spoke pattern 2 to 1, tubeless-ready, set 1450 gr, sealed cartridge bearings
Tire
Pirelli Cinturatoâ„¢ Velo TLR 32mm (622-32), ArmourTech
Cockpit
Stem
Velomann, AL6061, fully internal cable routing stem, compatible with Acros AICR system Ext: 90mm (47), 100mm(50/53), 110mm(55/57), 120mm(59/61)
Handlebar
Velomann Aero Compact handlebar full ICR, alloy diam. 31,8mm, reach 74mm, drop 116mm Size: 400mm-47~53cm, 420mm-55~57cm, 440-59"61cm
Grips / Extensions
Bianchi Arrow premium tape, 2.5mm thickness, full black
Saddle
Seatpost
Velomann, custom D-shape, alloy shaft 2014, head alloy 6061, Setback 25mm L350mm =47>57cm; L380mm= 59>61cm
Saddle
Velomann Mitora Lite 139 saddle, 139x250mm carbon rail 7x9,1mm
-
Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
